Samsung QB65H 65" Professional Display UHD WiFi Embedded 300CD/M2 Brightness 16/7 Operation 1456.1mm x 835.6mm x 37.5mm

  • In Stock
$3,611.00

SKU: QB65H

Calculate your shipping



Pick up at Rydalmere - $0.00
Pickup at our Rydalmere showroom. Please wait for the Pick Up Notification Email from us before arriving. Processing can take up to 24 Hours

Advertise your product or business digitally with the Samsung QBH Series 65"-Class UHD Commercial Smart Signage Display. Its edge-lit LED display panel with BLU technology features native resolution of 3840 x 2160 with 300 cd/m² bright output for viewing detailed high-definition content. Backed by the SSSP 5.0 platform and TIZEN 3.0 operating system, the display features a host of business-ready functionalities while also protecting business and customer data through enhanced security measures. It features an integrated media player and advanced graphic presentation. Its all-in-one design allows users to deliver targeted and personalized real-time messaging through the application-based Beacon management technology.


Highlights

  • 3840 x 2160 native resolution
  • 65" Wide screen offers more space for text and imagery
  • SSSP 5.0 platform with TIZEN 3.0 operating system improves overall performance while empowering business expandability
  • Reinforced security measures protect business and customer data
  • HDMI 2.0 and DisplayPort 1.2 connectivity
  • Expanded HDMI 2.0 connectivity allows for seamless daisy chaining
  • Ensures a consistent 60 Hz refresh rate and optimal clarity regardless of the source

Additional Features

  • Temperature sensor
  • Pivot display
  • Clock battery (168 hours clock keeping)
  • Two 10W built-in speakers
  • Integrated Wi-Fi
  • Auto source switching and recovery
  • LFD Home UI
  • Button lock
  • Hot key option
  • Plug-and-play (initial setting)

Panel

Diagonal Size 65
Type 60Hz E-LED BLU
Resolution 3840*2160 (4K UHD)
Pixel Pitch(mm) 0.105 x 0.315 (mm)
Active Display Area(mm) 1428.48(H) x 803.52(V)
Brightness(Typ.) 300 nit
Contrast Ratio 4000:01:00
Viewing Angle(H/V) 178/178
Response Time(G-to-G) 8ms (Typ)
Display Colors 16.7M(True Display) 1.07B(Ditherd 10bit)
Color Gamut 72%
Operation Hour 16/7
Haze 2%

Display

Dynamic C/R Mega H-Scanning Frequency 30 ~ 81kHZ
V-Scanning Frequency 48 ~ 75HZ Maximum Pixel Frequency 594MHz

Display

Speaker Type Built in Speaker(10W + 10W)

Connectivity

Input
RGB DVI-D, Display Port 1.2 (1)
Video HDMI 2.0 (2)
HDCP HDCP2.2
Audio Stereo mini Jack, DVI, HDMI
Usb USB 2.0 x 2
Output
RGB N/A
Video N/A
Audio Stereo mini Jack
Power Out N/A

External Control RS232C(in/out), RJ45
External Sensor IR
Tuner N/A

Power

Type Internal
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Max[W/h] 165
Typical[W/h] 122
BTU(Max) N/A
Sleep mode less than 0.5W
Off mode less than 0.5W

Mechanical Specification

Dimension (mm) Set 1456.1 x 835.6 x 37.5
Package 1574 x 949 x 212
Weight (kg) Set 22.8
Package 32.4
VESA Mount (mm) 400x400
Protection Glass N/A
Stand Type Foot Stand (Optional)
Media Player Option Type N/A
Bezel Width (mm) 12.2/12.2/12.2

Operation

Operating Temperature 0.0  ℃  ~   40.0   ℃ Humidity 10.0  %  ~   80.0   %

Feature

Key Features UHD Signage Display Slim & Light Signage with Built-in MagicInfo S5, SSSP 5.0
Special Features H/W : Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Wi-Fi S/W : Auto Source Switching & Recovery,LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player Processor Cortex A72 1.7GHz Quad-Core CPU
On-Chip Cache Memory L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
Clock Speed 1.7GHz Quad-Core CPU
Main Memory Interface 3GB 3ch 64bit LPDDR4 1.6GHz
Graphics 2D & 3D Graphic Accelerator Data Format : 32bpp Graphic resolution : 1920x1080 Output resolution : 3840x2160 (Scale up from graphic processing result.)
Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available)
Multimedia Video Decoder - MPEG 1/2/4, H.263, H.264/AVC - UHD H.264/AVC, VC-1, AVS/AVS+, MVC - VP8, VP9, HEVC, JPEG Audio DSP(Decoder) - MPEG, AC3, AC4, DD, MP3 and etc
IO Ports USB 2.0
Operating System Tizen 3.0 (VDLinux)

Certification

Safety 60950-1
EMC Class A

Accessory

Included Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional Stand -
Mount WMN6575SE
Specialty CLM450D

Media Player

Media Player SBB
SKU QB65H
Barcode # 887276239200
Brand Samsung

3 YEARS LIMITED WARRANTY
